| Camera |
|
| Image Sensor: |
| |
1/2.8" Progressive Scan CMOS |
|
| Effective Pixels: |
| |
1920(H)x1080(V) |
|
| Signal System: |
| |
PAL/NTSC |
|
| Minimum Illumination: |
| |
Color: 0.05 Lux @ (F1.6, AGC ON)
B/W: 0.01 Lux @ (F1.6, AGC ON)
0 Lux with IR |
|
| White Balance: |
| |
Auto/ Manual/ ATW (Auto-tracking White Balance)/ Indoor/ Outdoor/ Fluorescent Lamp/ Sodium Lamp |
|
| AGC: |
| |
Auto/ Manual |
|
| WDR: |
| |
120 dB WDR |
|
| Image Enhancement: |
| |
HLC/ BLC/ 3D DNR/ Defog/ EIS/ Regional Exposure/ Regional Focus |
|
| Shutter Time: |
| |
1/1 to 1/30,000s |
|
| Day& Night: |
| |
IR Cut Filter
|
|
| Digital Zoom: |
| |
16x |
| Optical Zoom: |
| |
25x |
|
| Privacy Masking: |
| |
24 programmable privacy masks
|
|
| Auto Focus: |
| |
Auto / Semi-automatic / Manual |
| Lens |
|
| Focal Length: |
| |
4.8 to 120mm |
|
| Zoom Speed: |
| |
Approx. 3.2s |
|
| Angle of View: |
| |
Horizontal field of view: 57.6° to 2.5° (wide-tele)
Vertical field of view: 34.4° to 1.4° (wide-tele)
Diagonal field of view: 64.5° to 2.9° (wide-tele) |
|
| Minimum Working Distance: |
| |
10 to 1500mm (wide-tele) |
|
| Aperture Range: |
| |
F1.6 to F3.5 |
| Pan & Tilt |
|
| Pan Range: |
| |
360°endless |
|
| Pan Speed: |
| |
Configurable, from 0.1°/s to 300°/s
Preset Speed: 350°/s |
|
| Tilt Range: |
| |
-5°~90° (Auto Flip) |
|
| Tilt Speed: |
| |
Configurable, from 0.1°/s to 160°/s
Preset Speed: 200°/s |
|
| Proportional Zoom: |
| |
Rotation speed can be adjusted automatically according
to zoom multiples |
|
| Number of Preset: |
| |
300 |
|
| Patrol: |
| |
8 patrols, up to 32 presets for each patrol |
|
| Pattern: |
| |
4 pattern scans, record time over 10 minutes for each
scan |
|
| Power loss recovery: |
| |
Support |
|
| Park Action: |
| |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
|
| PTZ Position Display: |
| |
ON/OFF |
|
| Freeze Frame: |
| |
Support |
|
| Scheduled Task: |
| |
Preset / Pattern / Patrol / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan / Dome Reboot / Dome Adjust / Aux Output |
| Infrared |
|
| IR irradiation distance: |
| |
50m |
|
| IR irradiation angle: |
| |
Adjustable by zoom |
Input & Output
|
|
| Alarm Input: |
| |
2 |
|
| Alarm Output: |
| |
2 |
|
| Audio Input: |
| |
Audio input (LINE input), 2-2.4Vp-p; output impedance: 1KO, ±10% |
|
| Audio Output: |
| |
1 Audio output interface
Line level, impedance: 600Ω
|
| Network |
|
| Ethernet: |
| |
10Base -T, /100Base-TX, RJ45 Connector |
|
| Max.Image Resolution: |
| |
1920×1080 (Full HD, 2MP, 16:9)
|
|
| Main Stream: |
| |
50Hz:
25fps (1920 × 1080, 1280 × 960, 1280 × 720),
50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz:
30fps (1920 × 1080, 1280 × 960, 1280 × 720),
60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
|
| Sub Stream: |
| |
50Hz: 25fps(704×576, 640x480,352×288);
60Hz: 30fps(704×480, 640x480,352×240) |
|
| Third Stream: |
| |
50Hz:
25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz:
30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
|
| Image Compression: |
| |
H.265+/ H.265/ H.264+/ H.264/ MJPEG
H.265 Type: Main Profile
H.264 Type: Baseline Profile/ Main Profile/ High Profile
Main Stream: H.265+/ H.265/ H.264+/ H.264
Sub-Stream: H.265/ H.264/ MJPEG
Third Stream: H.265/ H.264/ MJPEG |
|
| Video Bitrate: |
| |
32 Kbps to 16384 Kbps |
|
| Audio Compression: |
| |
G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
|
| Audio Bitrate: |
| |
64 Kbps (G.711)/ 16 Kbps (G.722.1)/ 16 Kbps (G.726)/ 32 Kbps to 160 Kbps (MP2L2) |
|
| SVC: |
| |
Support |
|
| Alarm Actions: |
| |
Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
|
| Protocols: |
| |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, NMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
|
|
| API: |
| |
Open-ended, support ONVIF, ISAPI, and CGI, support SDK |
|
| No. of Simultaneous Users: |
| |
Up to 20 users |
|
| Three-Stream: |
| |
Support |
|
| Mini SD Card: |
| |
Support up to 128GB Micro SD/SDHC/SDXC card.
Support Edge recording |
|
| User/Host Level: |
| |
Up to 32 users
3 levels: Administrator, Operator and User |
|
| Security Measures: |
| |
User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering |
| Client GUI |
|
| Camera Control: |
| |
Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
|
| Client: |
| |
Supported in Detec Next Software and most open-standard software brands |
|
| Web Browser: |
| |
Internet Explorer 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
| General |
|
| Menu Language: |
| |
English |
|
| Power Supply: |
| |
12 VDC &POE (802.3at,class4) |
|
| Power Consumption: |
| |
Max.: 18W (IR light 5W Max.) |
|
| Working Temperature/Humidity: |
| |
Outdoor: -30°C to 65°C (-22°F to 149°F)
Humidity: ≤ 90% |
|
| Material: |
| |
ADC12, PC, PC+ABS, SUS304, POM |
|
| Protection Level: |
| |
IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
|
| Dimensions: |
| |
Φ169.39mm ×161mm (Φ6.67"×6.34") |
|
| Weight (approx.): |
| |
Approx. 2.45kg (5.40lb) |
|
| Mounting Options: |
| |
Wall mount; DTC-BRKPTZ-WM, Corner mount adapter; DTC-BRKPTZ-CMA, Pole Mount Adapter; DTC-BRKPTZ-PMA, Power junction box mount; DTC-BRKPTZ-JBM; Short ceiling pendant mount; DTC-BRKPTZ-SCPM, Long ceiling pendant mount; DTC-BRKPTZ-LCPM, Roof parapet mount; DTC-BRKPTZ-RPM, Gooseneck surface mount: DTC-BRKPTZ-GSM |
