Camera
|
|
Image Sensor
|
1/2.8” 2Megapixel progressive scan CMOS
|
|
Effective Pixels
|
1920(H)x1080(V)
|
|
RAM/ROM
|
512MB/32MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual, 1/3~1/100000s
|
|
Minimum Illumination
|
0.006Lux/F1.6 ( Color,1/3s,30IRE)
0.05Lux/F1.6 ( Color,1/30s,30IRE)
0Lux/F1.6 (IR on)
|
|
S/N Ratio
|
Less than 50dB
|
|
IR Distance
|
Distance up to 50m(164ft)
|
|
IR On/Off Control
|
Auto/Manual
|
|
IR LEDs
|
3
|
|
Lens
|
|
Lens Type
|
Motorized
|
|
Mount Type
|
Board-in
|
|
Focal Length
|
2.7~13.5mm motorized
|
|
Max. Aperture
|
F1.6
|
|
Angle of View
|
H: 101° ~ 31°, V: 54° ~ 17°
|
|
Optical Zoom
|
5x
|
|
Focus Control
|
Motorized
|
|
Close Focus Distance
|
0.3m(0.98ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
W
|
44m(144ft)
|
18m(59ft)
|
9m(29ft)
|
4m(13ft)
|
|
T
|
143m(469ft)
|
57m(187ft)
|
28m(92ft)
|
14m(46ft)
|
|
Pan/Tilt/Rotation
|
|
Pan/Tilt/Rotation Range
|
Pan:0˚~355˚; Tilt:0˚~65˚; Rotation:0˚~355˚
|
|
Intelligence
|
|
IVS
|
Tripwire, Intrusion, Object Abandoned/Missing
|
|
Advanced Intelligent Functions
|
Face Detection
|
|
Video
|
|
Compression
|
H.265/H.264/H.264B/H.264H/MJPEG(sub stream)
|
|
Smart Codec
|
Support H.265+/H.264+
|
|
Streaming Capability
|
3 Streams
|
|
Resolution
|
1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ CIF(352×288/352×240)
|
|
Frame Rate
|
Main Stream: 1080P(1~25/30fps)
|
|
Sub Stream: D1 (1 ~ 25/30fps)
|
|
Third Stream: 1080P(1~25/30fps)
|
|
Bit Rate Control
|
CBR/VBR
|
