| Camera |
|
| Image Sensor |
1/2.8” 4Megapixel progressive scan CMOS |
| Minimum Illumination |
Color: 0.012Lux@F1.4, B/W: 0Lux with IR on |
|
| WDR |
120dB Super WDR |
| Shutter Time |
1/100000s-1s |
| IR Distance |
Up to 50 m |
| Day/Night Mode |
Day/Night/Auto/Customize/Schedule |
| S/N |
>55dB |
| Lens |
|
| Lens Type |
Motorized 2.7-13.5mm@F1.4 |
| Field of View |
H107°~H33°/D125°~D37° /V58°~V1 |
| Mount |
Φ14 |
| Focus Control |
Auto/Manual |
| Video |
|
| Max. Image Resolution |
3840x2160 |
| Primary Stream |
z/50Hz: 30fps@(3840x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576), 20fps(3840x2160)(Optional for S
Series) |
| Secondary Stream |
60Hz: 30fps@(704x576, 640x480, 640x360, 352x288)
50Hz: 25fps@(704x576, 640x480, 640x360, |
| Tertiary Stream |
60Hz: 30fps@(1280x720, 704x576, 640x480, 640x360, 352x288)
50Hz: 25fps@(1280x720, 704x576, 640x480, 640x360, |
| Video Compression |
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Video Bit Rate |
16Kbps~16Mbps(CBR/VBR Adjustable) |
| Privacy Masking |
Up to 4 Areas |
| ROI |
Up to 4 areas |
| Image Setting |
Brightness/Contrast/Saturation/Sharpness |
| Interface |
|
| Ethernet |
1*RJ45 10M/100M Ethernet Port |
| Audio |
Built-in Microphone |
| Lens |
|
| Network Storage |
NAS(Support NFS, SMB/CIFS), ANR |
| Protocol |
IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL |
| Audio |
|
| Audio Compression |
G.711/AAC/G.722/G.726 |
| Audio Sampling Rate |
8/16/32/48KHz |
| Audio Bit Rate |
16~256kbps |
| Two-way Audio |
Support |
| Intelligent Analytics |
|
| Video Analysis |
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed |
| System |
|
| Storage |
Support microSD/SDHC/SDXC Card Local Storage, up to 256G |
| Advanced Function |
BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur |
| SIP/VoIP Support |
Yes, Voice & Video-over-IP |
| Event Trigger |
Motion Detection, Network Disconnection, External Input, Audio Alarm, etc |
| Event Action |
FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc. |
| System Compatibility |
ONVIF Profile G & Q & S & T, API |
| General |
|
| Working Temperature |
-40℃-60℃ |
| Working Humidity |
0-90% (Non-condensing) |
| Power Supply |
PoE (802.3af); PoE (802.3af) / DC 12V±10% (Multi-interface Version |
| Power Consumption |
7.4W MAX
8.4W MAX (With IR on)
|
| Housing |
Vandal-proof IK10-rated Metal Housing / Up to IP67-rated for Weather-resistant Performance |
| Weight |
780g |
| Dimensions |
Φ130mmX115mm |
