SPECIFICATIONS |
| Thermal |
|
| Image Sensor: |
Vanadium Oxide Uncooled Focal Plane Detectors |
| Effective Pixels: |
640(H)x512(V), 327.680 |
| Detector Pitch: |
17um |
| Spectral Range: |
8~14µm |
| Noise Equivalent Temperature Difference (NETD): |
< 40mk(@25°C,F#=1.0) |
| Reference Object Size: |
Human: 1.8*0.5m Vehicle: 1.4*4.0m |
|
Field of View (FOV):
|
17.67°×14.18° |
| Lens: |
35mm |
| MRAD: |
0.49 |
| Detection range - Vehicles: |
3157m |
| Detection range – Humans: |
1029m |
| Recognition range - Vehicles: |
789m |
| Recognition range – Humans: |
257m |
| Identification range - Vehicles: |
395m |
| Identification range – Humans: |
129m |
| F number: |
1.0 |
| Network |
|
| Ethernet: |
1 RJ45 10M/100M Self-adaptive Ethernet interface |
| Max. Image Resolution: |
640×512 |
| Main Stream: |
50Hz: Max. 50fps (640x512, 384×288, 352x288) |
| Sub Stream: |
50Hz: Max. 50fps (640x512, 384×288, 352x288) |
| Third Stream: |
50Hz: Max. 50fps (640x512, 384×288, 352x288) |
|
|
| Video Compression: |
H.264/MJPEG/MPEG4, H.264 encoding with Baseline/Main/High profile, H.264+, ONVIF support |
| Audio Compression: |
G .711u/G.711a/G.722.1/MP2L2/G726/PCM |
| Protocols: |
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| No. of Simultaneous Users: |
Up to 20 users |
| User/Host Level: |
Up to 32 users,3 Levels: Administrator, Operator and User |
| Security Measures: |
User authentication (ID and PW)
MAC address binding
HTTPS encryption
IEEE 802.1x access control
IP address filtering |
| Integration |
|
| Client: |
Supported in Detec Next VMS and most open-standard software brands |
| Web Browser: |
IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 + |
| Alarm input: |
2 inputs (0-5vDC) |
| Alarm output: |
2 relay outputs, alarm response actions configurable |
| Alarm action: |
SD recording/Relay output/Smart capture/FTP upload/Email linkage |
| Audio input: |
1 3.5mm Mic in/Line in interface. Line input: 2-2.4V[p-p], output impedance:1KO±10% |
| Audio output: |
Line level, impedance: 600O |
| Reset: |
1 Reset button |
| SD memory card: |
Built-in Micro SD card slot, support Micro SD/SDHC/SDXC card (up to 64G), support manual/alarm recording |
| Analog video output: |
1.0V[p-p] / 75O, PAL(or NTSC), BNC |
| General |
|
| Menu Language: |
English |
| Power Supply: |
24 VAC, 12 VDC, PoE (802.3.at) |
| Power Consumption: |
Default 6W, 18W max (lens de-icing enabled) |
| Working Temperature/ Humidity: |
-40°C - 60°C (-40°F - 140°F)
95% or less (non-condensing) |
| Protection Level: |
IP66 |
| Dimensions: |
314 x 104 x 104mm |
| Weight (approx.): |
2kg (approx.) |
