Camera
|
|
Image Sensor
|
Two 1/2.8” 2Megapixel progressive scan CMOS
|
|
Effective Pixels
|
1920(H)x1080(V)
|
|
RAM/ROM
|
512MB/256MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual, 1/3(4)~1/100000s
|
|
Minimum Illumination
|
0.009Lux/F2.0( Color,1/3s,30IRE)
0.07Lux/2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
|
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 20m (66ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
10 x 2
|
|
Lens
|
|
Lens Type
|
Fixed
|
|
Mount Type
|
Board-in
|
|
Focal Length
|
2.8mm (3.6mm optional)
|
|
Max. Aperture
|
F2.0 (F2.1)
|
|
Angle of View
|
H: 110° (86°), V:60° (46°)
|
|
Optical Zoom
|
N/A
|
|
Focus Control
|
Fixed
|
|
Close Focus Distance
|
N/A
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
41m(134ft)
|
16m(52ft)
|
8m(26ft)
|
4m(13ft)
|
|
3.6 mm
|
55m(180ft)
|
22m(72ft)
|
11m(36ft)
|
6m(20ft)
|
|
Pan/Tilt/Rotation
|
|
Pan/Tilt/Rotation Range
|
Pan:±90˚; Tilt:0˚~65˚; Rotation:0˚~360˚
|
|
Intelligence
|
|
Event Trigger
|
Motion detection, Video tampering, Scene changing,
Network disconnection, Ip address conflict, Illegal
access, Storage anomaly
|
|
IVS
|
Tripwire, Intrusion, Object Abandoned/Missing
|
|
Advanced Intelligent Functions
|
Face Detection
|
|
Video
|
|
Compression
|
H.265/H.264H/MJPEG(Sub Stream)
|
|
Smart Codec
|
N/A
|
|
Streaming Capability
|
2 Streams
|
|
Resolution
|
1080P(1920x1080)/1.3M(1280x960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
|
|
Frame Rate
|
Main Stream:
CH1: 1080P (1~25/30fps)
CH2: 1080P (1~25/30fps)
|
|
Sub Stream:
CH1: D1(1~25/30fps)
CH2: D1(1~25/30fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Bit Rate
|
H.264: 32~10240Kbps
H.265: 12~7168Kbps
|
|
Day/Night
|
Auto(ICR) / Color / B/W
|
|
BLC Mode
|
BLC / HLC / WDR（120dB）
|
|
White Balance
|
Auto/Natural/Street Lamp/Outdoor/Manual
|
|
Gain Control
|
Auto/Manual
|
