Detec AS - A Safe Choice

Detec DTC-2241-24-RAD, 4MP, IP67, IR35m, 256 x 192 (3.5 mm), 50.6° x 37.8°, 25fps

Detec DTC-2241-24-RAD, 4MP, IP67, IR35m, 256 x 192 (3.5 mm), 50.6° x 37.8°, 25fps

Regular price
Regular price Sale price
Sale Sold out
Shipping calculated at checkout.

Key Features

Download

  • Heat detection and alarm, tripwire, intrusion, and target filtering
  • 1/2.7" 4 Megapixel progressive scan (CMOS) 25 fps
  • H.265, Two-way Audio, I/O PoE, Micro SD
  • Vanadium oxide uncooled focal plane detector
  • RAD-SENSOR
  • Offers various AI functions such as intrusion, target filtering, heat detection, smoking detection, and call detection.
  • Built-in white light and speaker that produce light and sound alarms to deter intruders
  • Temperature measurement range of –20 °C to +550 °C

Approved for use with

DETEC NEXT FIRE

Radiometric thermal camera module with both temperature and radiant energy measurement customized for use with Detec
Next RAD Camera License on Detec Next VMS
Edge analysis on camera to be used with other types of Detec
Next camera licenses.
Reliable temperature exception alarm function
Advanced fire detection algorithm
Very early notification of potential fires to the fire service/control center, for use at i.e:
 - Detection in larger wooden building areas
 - Preventive fire detection and monitoring at garbage facilities

Thermal

Detector Type

Vanadium oxide uncooled focal plane detector

Effective Pixels

256 (H) × 192 (V)

Pixel Pitch

12 μm

Spectral Range

8 μm–14 μm

Sensitivity (NETD)

≤40 mK (@f/1.0)

Field of View

3.5 mm: H: 50.6°; V: 37.8°

Thermal Focus Control

Fixed-focal

Close Focus Distance

3.5 mm: 0.5 m

Image Sensor

1/2.7" CMOS

Max. Resolution

2336 (H) × 1752 (V)

Pixel

4 MP

Min. Illumination

Color: 0.05 lux B/W: 0.005 lux 0 lux (IR on)

Visible AGC

Auto/Manual

Visible Noise Reduction

2D NR/3D NR

S/N Ratio

≥55 dB

White Balance

Auto; manual; indoor; outdoor; tracking; sodium lamp;
street lamp; natural

Defog

Electronic defog

WDR

Yes

Day/Night

Auto (ICR); Color; B/W

Iris Control

Fixed

Image Flip

90°; 180°; 270°
